API “The BOX” Operator’s Manual

3.3 Output Routing and Pan-Pot

Each summing input can be routed to the program bus via the PGM assignment

switch. The program bus is fed post-fader/mute and pan-pot.

Program Bus Assignment

Stereo Pan-Pot

PGM (Program): Assigns the summing channel output to the program

bus when engaged

• Program bus is fed post-pan-pot

• Illuminates when engaged

PAN (pan-pot): Continuously variable left-right stereo pan-pot

• Program bus is fed post-pan-pot

• -3dB pan law (-3dB per side when panned center)

• Center detent
